Product Details:
|
| Material: | Al2O3,Cr2O3 | Other Names: | Pink Fused Alumina,PA,Pink Corundum |
|---|---|---|---|
| Color: | Light Pink | Grits: | F24,F36,F60,F80,F120...F2000 |
| Usage: | Bonded Abrasive,Refractory,Sand Blasting | Name: | 46 Grit Pink Aluminum Oxide / Amphoteric Oxide |
| High Light: | 46 grit pink aluminum oxide,amphoteric pink aluminum oxide,46 grit pink alumina |
||
Al2o3 F24 Fused Pink Aluminum Oxide Blast Media
Pink Fused Alumina Is A Kind Of Pure Abrasive (al2o3 Purity 96.5-99%)
High Toughness And Self-sharpening
High Hardness With Sharp Edges Of Crystals.
Durable, Hard, And Resists High Pressure
High Abrasive Resistance
It Does Not Contain Iron Under Normal Conditions
It Has A Structure Suitable For Wet And Dry Sandblasting Applications
Pink Fused Alumina, also called Pink Fused Aluminium Oxide, Chromium Aluminum Oxide, abbreviated as "PA",belongs to the group of artificial corundum. It's made from fusion of high purity alumina powder and chromium oxide in electric arc furnace. Because of its chrome content, it's a pink color material. Its main content is Aluminium Oxide(Al2O3), with little content(about 0.7% Chromium Oxide and about 0.3% Sodium Oxide(Na2O). Pink Fused Aluminium Oxide is a hard, tough, self-sharpening, low magnetic, coarse grits, pure and clean abrasive material. Compared to White Fused Aluminium Oxide, it has similar hardness, while better strength and cutting side. It's widely used in production of vitrified grinding wheel, resinoid grinding wheel, cutting discs, grinding head and other abrasive tools, also for sandblasting abrasvies, polishing, free grinding, cutting etc.
Chemical composition
| Size | Low chromium | Medium chromium | High chromium | ||||||
|
Al2O3 (%) |
Cr2O3 (%) |
Na2O (%) |
Al2O3 (%) |
Cr2O3 (%) |
Na2O (%) |
Al2O3 (%) |
Cr2O3 (%) |
Cr2O3 (%) |
|
| F12~F80 |
≥98.50
|
0.20~ 0.45 |
≤0.50 |
≥98.20
|
0.45~ 1.00 |
≤0.55 |
≥97.40
|
1.00~ 2.00 |
≤0.55 |
| F90~D150 |
≥98.50
|
≤0.55 |
≥98.20
|
≤0.60 |
≥97.00
|
≤0.60 | |||
| F180~F220 |
≥98.00
|
≤0.60 |
≥97.80
|
≤0.70 |
≥96.50
|
≤0.70 |
|||
Physical property:
| Basic minerals |
Crystal size um |
True density |
Bulk density g/cm3 |
Knoop hardness kg/mm2 |
| α~Al2O3 | 600~800 | ≥3.90 | 1.40~1.91 |
2200~2300 |
